SPECIFICATIONS
|
Model No: |
ACE (PST150-12) |
| Engine Type | Single Cylinder, 4-strokes |
| Cooling | Air Cooled |
| Drive System | BELT/CHAIN |
| Piston Displacement | 149.6cc |
| Bore and Stroke | 2.26 inches x 2.28 inches |
| Compression Ratio | 10.3:1 |
| Maximum Power | 6.2/7500kw/r/min |
| Maximum Torque | 8.2/6500N.m./rpm |
| Starter | Electric / Kick |
| Transmission | Automatic |
| Length | 76.7 inches |
| Width | 39.7 inches |
| Height | 44.1 inches |
| Seat Height | 33.1 inches |
| Wheelbase | 59 inches |
| Ground Clearance | 2.8 inches |
| Front Brake | Disc |
| Rear Brake | Disc |
| Front Tire | 120x70-12 |
| Rear Tire | 205 x50-10 |
| Ignition | CDI |
| Maximum Speed | 49.7 mph |
| Gross Weight | 330 lbs |
| Weight Capacity | 320 lbs |
| Battery | 12V/7Ah |
| Frame | Steel |
| Packing Size | 75.6 inches x 34.2 inches x 47.2 inches |
| Towing Capacity | 66 lbs |
| Fuel Capacity | 1.2 gal |
| Make of Tire (Front/Rear) | KENDA/CHENGSHIN |
