ENGINE
|
|
Type
|
125cc,风冷(Air cooled),4冲程(4-stroke),单缸(1-cylinder)
|
|
Bore x Stroke
|
52.4mmX55.5mm
|
|
Compression Ratio
|
9.1:1
|
|
Carburetor
|
PZ20
|
|
Ignition
|
CDI
|
|
Starting Time
|
(Electric start)
|
|
Transmission
|
(R-N-F)
|
|
Drive Train
|
(Chain Drive)
|
|
Max. Torque
|
8.0N.m/5500r/min
|
|
Max. Power
|
5.3kw/7500r/min
|
|
CHASSIS
|
|
Suspension/Front
|
(Independent double swing arm)
|
|
Suspension/Rear
|
Single swing arm)
|
|
Brakes/Front
|
Drum）
|
|
Brakes/Rear
|
(Ventilated Hydraulic disc)
|
|
Tires/Front
|
19 x 7-8半径(19x 7-8 radial)
|
|
Tires/Rear
|
18x 9.5-8半径(18x9.5-8radial)
|
|
DIMENSIONS
|
|
L x W x H
|
1440mmX940mmX940mm
|
|
Seat Height
|
710mm
|
|
Wheelbase
|
960mm
|
|
Ground Clearance
|
135mm
|
|
Front track
|
760mm
|
|
Rear track
|
670mm
|
|
Battery
|
12V/5Ah
|
|
Fuel Capacity
|
2L
|
|
Dry Weight
|
106KG
|
|
Max. Load
|
75KG
|
|
Package Size
|
53.9X30.3X24.8 IN
|
|
Loading Quantity
|
96台/40高柜 (96pcs/40HQ)
|
|
MAIN PERFORMANCE
|
|
Max. Speed
|
48km/h
|
|
Fuel Consumption
|
2.6L/100kg
|
|
Starting Time
|
≤15s
|
|
Brake distance
|
30km/h≤6.5m
|
