Engine System
|
Engine Type
|
ZM125cc, Single Cylinder, 4-Stroke, Air Cooled
|
Displacement
|
124 ml
|
Max Power
|
6.2(1±10%)/7000(1±5%) kw/r/min
|
Max Torque
|
9.0(1±10%)/5000(1±5%) N.m/r/min
|
Compression Ratio
|
9.6:1
|
Shift Type
|
4 Speed Simi Automatic
|
Start Type
|
Kick Start
|
Carburetor
|
PZ26 Jingke Carburetor
|
Drive Train
|
#428,14/41T
|
Size Data
|
L x W x H
|
64.1" * 29.5" * 41.3"
|
Wheel Base
|
42.3"
|
Tires
|
FT: 60/100-14 - RR: 80/100-12
|
Seat Height
|
29.6"
|
Ground Clearance
|
13.5
|
Fuel Capacity
|
3.5 L
|
Frame/Suspension/Brake/Wheel system
|
Frame
|
Cradle Type Steel Tube Frame
|
Front Fork
|
Non-Adjustable Inverted 700mm Forks, Travel - 4.3" , Tube - 1.2"
|
Rear Shock
|
Coil Spring shock - 10.8" , Travel - 1.6"
|
Swing-Arm
|
Steel - 14.9"
|
Handle Bar
|
Steel
|
Wheels
|
Steel 1.6 x 17" / 1.85 x 14" Rims, Cast Hubs
|
Front Brake
|
Single Piston Caliper, 210mm Disc
|
Rear Brake
|
Single Piston Caliper, 190mm Disc
|
Exhaust
|
Stainless Steel Header Pipe, Haxagon Aluminum Silencer
|
Packing and Loading
|
Packing Size
|
L 53" X W 15" X H 26"
|
N.W/KG
|
145.5 LBS
|
G.N/KG
|
155 LBS
|
