SPECIFICATIONS



ENGINE INFO:                DB-36 250cc Manual Clutch 5 Gears

Engine Type:

250cc Air cooled,4 stroke

Transmission:

Manual (5 Gears)

Starter mode:

Electric and Kick start

Max Power:

13KW/700rpm



CHASSIS/

SUSPENSION/BRAKES



Front Suspension:

54mm wide inverted Front forks with265mm travel and 910mm length

Rear Suspension:

Adjustable

Braking system:

Front and Rear Hydraulic disc

Frame:

Twin spar heavy duty steel frame



Dimensions



Seat Height:

930mm

Wheel Base:

1420mm

Front and Rear Wheel:

80/100-21"   110/90-18"

Tank Capacity:

7L

GW/NW:

128/108Kg


Download
DB36 Parts Diagram.xls
Microsoft Excel Table 1.1 MB
