Technical specification
1) Engine type: Single Cylinder, 4 Stroke, Air-Cooled, Horizontal type



2) Displacement(ml): 49.4



3) Max Power(kw/r/min): 2.4/7500
4) Max Torque (Nm. /r/min): 3.0/6000
5) Ignition system: CDI



6) Gear: CVT



7) Fuel tank capacity(L): 5.0



8) Economical oil exhaust(L/100km): 2.5



9) Max speed: Up to 25mph (may vary with rider weight, road condition and/or other factors)



10) Transmission: Belt Drive
11) Brake Type (front / rear): Disc Brake / Drum Brake



12) Wheelbase(mm): 1375
13) Ground clearance(mm): 190
14) Tires (front / rear): 120/70-12   130/70-12



15) N. W.(kg): 90     G. W.(kg):   117



16) Product dimension(mm): 1870*770*1140



17) Carton dimension(mm): 1900*575*1140/1710*540*820



Download
NINJA 49CC-Parts Diagram.xlsx
Microsoft Excel Table 4.0 MB
