SPECIFICATIONS:





Engine Type:

4-Stroke, air cooled (GY6)



Displacement:

49CC



Compression Ratio:

10.5:1



Cylinder Diameter:

39 mm



Piston Stroke:

41.5 mm



Transmission:

CVT automatic



Ignition Methods:

CDI



L x W x H:

66” x 25” x 42”



Wheel Base:

47.2”



Dry Weight:

166LBS



Max Loading Weight:

331LBS



Brake / Front:

Disk



Brake / Rear:

Drum



Tire / Front:

3.5-10



Tire / Rear:

3.5-10



Suspension / Front:

Hydraulic telescopic fork



Suspension / Rear:

Thickened spring damping



Fuel Capacity:

5 L



Fuel Consumption:

2.5 L / 100 km



Max Speed:

Up to 25mph (may vary with rider weight, road condition and/or other factors)



Max Power:

2.4 / 7500 (kw/ rpm)



Max Torque:

2.7 / 6000 (Nm. / rpm)



Rpm:

1600 ±100



Seat Height:

28.3”



Ground Clearance:

3.9”
