SPECIFICATIONS: |
|
|
Engine Type: |
4-Stroke, air cooled (GY6) |
|
Displacement: |
49CC |
|
Compression Ratio: |
10.5:1 |
|
Cylinder Diameter: |
39 mm |
|
Piston Stroke: |
41.5 mm |
|
Transmission: |
CVT automatic |
|
Ignition Methods: |
CDI |
|
L x W x H: |
66” x 25” x 42” |
|
Wheel Base: |
47.2” |
|
Dry Weight: |
166LBS |
|
Max Loading Weight: |
331LBS |
|
Brake / Front: |
Disk |
|
Brake / Rear: |
Drum |
|
Tire / Front: |
3.5-10 |
|
Tire / Rear: |
3.5-10 |
|
Suspension / Front: |
Hydraulic telescopic fork |
|
Suspension / Rear: |
Thickened spring damping |
|
Fuel Capacity: |
5 L |
|
Fuel Consumption: |
2.5 L / 100 km |
|
Max Speed: |
Up to 25mph (may vary with rider weight, road condition and/or other factors) |
|
Max Power: |
2.4 / 7500 (kw/ rpm) |
|
Max Torque: |
2.7 / 6000 (Nm. / rpm) |
|
Rpm: |
1600 ±100 |
|
Seat Height: |
28.3” |
|
Ground Clearance: |
3.9” |
