Model:
|
AGA-10
|
Seat Height:
|
22.8"
|
|
Model series:
|
commander
|
Curb weight:
|
169.7 lbs
|
|
Engine Type:
|
Single cylinder 4 stroke
|
Rated Payload:
|
143.3 lbs
|
|
Clutch:
|
automatic with reverse - hand shift
|
MAX Speed:
|
40km/h
|
|
Displacement:
|
106.7cc
|
MINI turning radius:
|
98.4"
|
|
Bore&Stroke:
|
52.4mm×49.5mm
|
MAX gradeability:
|
10°
|
|
Compression rate:
|
9.7:1
|
Front Brake:
|
Drum brake-handle
|
|
MX Power:
|
5.0kW/8000rpm
|
Rear Brake:
|
Hydraulic brake-handle
|
|
MX torque:
|
5.9N.m/6000rpm
|
Front Tire:
|
145/70-6
|
|
Idle Speed:
|
1500±100r/min
|
Rear Tire:
|
145/70-6
|
|
Min.fuel consumption:
|
≤367g/kW·h
|
Tire pressure F.:
|
10P.S.I.
|
|
sparking mode:
|
CDI
|
Tire pressure R.:
|
10P.S.I.
|
|
starting mode:
|
Electric
|
Driving Method:
|
Chain Drive
|
|
Fuel:
|
RQ-93
|
Clutch:
|
automatic with reverse multichip
|
|
lubricating system:
|
Pressure and splash
|
Spark plug:
|
LGD8TC
|
|
Engine Oil:
|
SAE15W/40
|
Carburetor:
|
PZ19
|
|
Vehicle desc:
|
Single seat、Chain drive、Rear wheel drive
|
Battery:
|
12V、5Ah
|
|
Vehicle Type:
|
G
|
Fuel Tank:
|
2.5L
|
|
Product Size:
|
47.2"×29.3"×30.9"
|
Packing Size:
|
44.8"×27.5"×23.2"
|
|
Axle Base:
|
31.6"
|
N.W.:
|
165.3 lbs
|
|
Track front:
|
24.2"
|
G.W.:
|
194 lbs
|
|
Track rear:
|
21.6"
|
40HQ loading:
|
136pcs/40'HQ
|
|
Ground clearance:
|
3.1"
|
|
|
