Specification
|
|
Model Code
|
SX-E5
|
|
Age of Use
|
6-8 years old
|
|
Height
|
120-140cm
|
|
Battery
|
48V 25AH
8C High rate lithium battery
|
|
Battery weight
|
7.8 Kg
|
|
Motor
|
48V 2Kw MAX 5Kw
|
|
Motor weight
|
7.5 Kg
|
|
Range
|
30km(35km/h)
|
|
Charge
|
DC:54.6V 4.5A@6H
|
|
Charge weight
|
1 Kg
|
|
Meter
|
LED
|
|
APP
|
√
|
|
Power off switch
|
√
|
|
Peak HP
|
6.80
|
|
Motor torque
|
45N.m
|
|
Gear ratio
|
13:44
|
|
Wheel torque
|
145N.m
|
|
Top speed:
|
60km/h
|
|
Seat height
|
670-645-620mm
|
|
Wheelbase
|
1040mm
|
|
Steering angle
|
42°
|
|
Ground clearance
|
215mm
|
|
Wheel diameter
|
F 60/100-12
R 70/100-10
|
|
Front suspension
|
Φ35-690mm / 200mm
|
|
Rear suspension
|
275mm / 180mm
|
|
Rear shock spring
|
300 Lb
|
|
Handlebar
|
Φ28.5-22-19*660mm
|
|
Brake type
|
F / R Single piston
|
|
Brake disc diameter
|
F 160mm / R 160mm
|
|
Frame material
|
BIK500 High-strength Steel
|
|
Rear fork material
|
6061 Forged Aluminum Alloy
|
|
Weight
|
47 kg
|
|
Product size
|
1450*680*900mm
|
|
Packing size
|
1320x325x660mm
|
|
Packing quantity
|
40HQ:248Pcs
|
|
Packing weight
|
63 Kg
|
|
Max Load
|
55 Kg
|
