SPECIFICATIONS
Engine and transmission |
Displacement(cc) | 150 |
Engine type | 1P57QMJ | |
Engine mode | 1-cylinder/4-stroke/2-valve | |
Bore x stroke(mm) | ø57.4x57.8 | |
Max.power | 6.6kW/7500 r/min | |
Max.torque | 9.3N·m/6000 r/min | |
Compression ratio | 9.5:1 | |
Fuel system | Carburetor | |
Valve train | SOHC | |
Ignition | C.D.I. | |
Starter | Electric & Kick | |
Lubrication system | Pressure splash lubrication | |
Cooling system | Forced-air-cooled | |
Gear shifting type | Automatic CVT | |
Transmission type final drive |
V-Belt | |
Clutch type | Automatic | |
Physical measures | Dry weight(kg) | 105 |
Seat height(mm) | 775 | |
Overall length (mm) | 1890 | |
Overall width (mm) | 748 | |
Overall height (mm) | 1080 | |
Ground clearance (mm) | 118 | |
Wheelbase (mm) | 1287 | |
Chassis and dimensions | Frame type | Flat scooter |
Front suspension (Inverted) | Telescopic forks | |
Front suspension travel (mm) | 120 | |
Rear suspension | Mono-shock-absorber | |
Rear suspension travel (mm) | 55 | |
Fr. tyre | 90/90-12 | |
Rr. tyre | 3.5-10 | |
Fr. Brakes | Disc | |
Fr. brakes diameter (mm) | 220 | |
Rr. brakes | Drum | |
Rear brakes diameter (mm) | 110 | |
Other specifications | Top speed(MPH) | 56 |
Max.loadage (kg) | 75*2=150kg | |
Fuel capacity(L) | 9 | |
Battery | 12V6Ah(YTX7A-BS) |
